2-5 Fixed WiMAX Demodulator Chapter 2 —Fixed WiMAX Signal Analyzer
2-8 PN: 10580-00236 Rev. D WiMAX MG
2-5 Fixed WiMAX Demodulator
This instrument can demodulate a Fixed WiMAX Signal from a Base Station and can display
the results in Constellation, Spectral Flatness, EVM versus Sub Carrier, EVM versus
Symbol, and Modulation Summary views.
Setup for Fixed WiMAX Demodulator Measurements
1. Press the Setup main menu key.
2. Set the bandwidth, frame length, and CP Ratio as described in the “General
Measurement Setups” on page 2-3.
Constellation
The instrument displays the constellation of the demodulated data symbols over one frame.
The various constellations are color coded for modulation as follows:
• BPSK is shown in orange.
• QPSK is shown in purple.
• 16QAM is shown in green.
• 64QAM is shown in yellow.
The numerical results that are displayed in this view are: RCE (rms) in dB, RCE (pk) in dB,
EVM (rms) in %, EVM (pk) in %, Freq Error in Hz, Freq Error in ppm, Carrier Frequency
in Hz, and Base Station ID.
Procedure:
1. Setup the measurement as described in “Setup for Fixed WiMAX Demodulator
Measurements” on page 2-8.
2. Press the Measurements main menu key.
3. Press the Demodulator submenu key.
4. Press the Constellation submenu key to activate the measurement.
5. Press the Constellation submenu key again to activate the reference points menu.
6. Press the Reference Points submenu key to switch the reference points On
or Off
(refer to “Demodulator Menu” on page 2-22.
