3-11 Measurements Menu Chapter 3 —Mobile WiMAX Signal Analyzer
3-24 PN: 10580-00236 Rev. D WiMAX MG
3-11 Measurements Menu
Key Sequence: Measurements
RF: Press this submenu key to open the “RF Measurements Menu” on
page 3-25.
Demodulator: Press this submenu key to open the “Demodulator Menu”
on page 3-26.
OTA: Press this submenu key to open the “Over-The Air Menu” on
page 3-28.
Pass/Fail Mode: Press this submenu key once to display the PASS_FAIL
table. Press the key again to open the Pass/Fail submenu key menu
(refer to “Pass Fail Mode Menu” on page 3-29).
Pass/Fail mode allows the selection of a user-defined file that specifies a
list of measurements with pass/fail criteria. This mode moves in sequence
through the appropriate measurements and indicates a pass or fail state
based for each of the criteria. A custom test list can be created with Master
Software Tools and can be uploaded into your instrument. All critical
measurements can be selected for pass fail testing. The results are
displayed in table format with clear identification of pass/fail results,
including minimum and maximum thresholds and measured results.
WiMAX Summary: Press this submenu key to display a summary of all of
the WiMAX-related numerical measurement results.
• Channel power (dBm)
• Downlink Burst Power
• Preamble Power
• Occupied Bandwidth
• Uplink Burst Power
• RCE (rms)
• RCE (pk)
• EVM (rms)
• EVM (pk)
• Carrier Frequency
• Freq Error
• CINR
• Base Station ID
• Sector ID
Save Measurement: Initiates a dialog box to name and save the current
measurement. The saved measurement can be named by using the keypad
to select numbers, the rotary knob to highlight a number or character and
pressing the knob to select, or by pressing the submenu key for each letter.
Use the Shift key to select an upper case letter. Use the Left/Right
directional arrow keys to move the cursor position. Press Enter to save.
WiMAX measurements are saved with a .wmxe extension.
Figure 3-21. Mobile WiMAX Measurements Menu
Measurements
Save
Measurement
Pass/Fail Mode
WiMAX
Summary
RF Measurements
Demodulator
OTA
