Anybus CompactCom 40 EtherNet/IP User Manual

102
Doc.Id. HMSI-27-212
Anybus CompactCom 40 EtherNet/IP
Doc.Rev. 1.5
Instance Attributes (Instance #8, Ethernet Communication Settings 2)
Changes have immediate effect.
Extended
Instance Attributes (Instance #9, DNS1)
This instance holds the address to the primary DNS server.
Extended
# Name Access Type Description
1
Name
a
a. Multilingual, see “Multilingual Strings” on page 107.
Get Array of CHAR ‘Comm 2’
2 Data type Get UINT8 08h (= ENUM)
3 Number of elements Get UINT8 01h (one element)
4 Descriptor Get UINT8 07h (read/write/shared access)
5
Value
a
Get/Set ENUM Value:Enum. String:Meaning:
00h ‘Auto’ Auto negotiation (default)
01h ‘10 HDX’ 10Mbit, half duplex
02h ‘10 FDX’ 10Mbit, full duplex
03h ‘100 HDX’ 100Mbit, half duplex
04h ‘100 FDX’ 100Mbit, full duplex
6 Configured Value Get ENUM Holds the configured value, which will be written to attribute
#5.
Value:Enum. String:Meaning:
00h ‘Auto’ Auto negotiation (default)
01h ‘10 HDX’ 10Mbit, half duplex
02h ‘10 FDX’ 10Mbit, full duplex
03h ‘100 HDX’ 100Mbit, half duplex
04h ‘100 FDX’ 100Mbit, full duplex
# Name Access Type Description
1
Name
a
a. Multilingual, see “Multilingual Strings” on page 107.
Get Array of CHAR ‘DNS1’
2 Data type Get UINT8 04h (= UINT8)
3 Number of elements Get UINT8 04h
4 Descriptor Get UINT8 07h (read/write/shared access)
5 Value Get/Set Array of UINT8 Any change is valid after reset.
Valid range: 0.0.0.0 - 255.255.255.255 (Default =0.0.0.0)
6 Configured Value Get Array of UINT8 Holds the configured value, which will be written to attribute
#5 after the module has been reset.
Valid range: 0.0.0.0 - 255.255.255.255 (Default =0.0.0.0)
