Anybus CompactCom 40 EtherNet/IP User Manual

151
Doc.Id. HMSI-27-212
Anybus CompactCom 40 EtherNet/IP
Doc.Rev. 1.4
Exception Information
If Exception Code 09h is set in the Anybus object, there is an error regarding the functional safety mod-
ule in the application. Exception information is available in instance attribute #10 according to this table:
Value Exception Information
00h No information
01h Baud rate not supported
02h No start message
03h Unexpected message length
04h Unexpected command in response
05h Unexpected error code
06h Safety application not found
07h Invalid safety application CRC
08h No flash access
09h Answer from wrong safety processor during boot loader communication
0Ah Boot loader timeout
0Bh Network specific parameter error
0Ch Invalid IO configuration string
0Dh Response differed between the safety microprocessors (e.g. different module types)
0Eh Incompatible module (e.g. supported network)
0Fh Max number of retransmissions performed (e.g. due to CRC errors)
10h Firmware file error
11h The cycle time value in attribute #4 in the Functional Safety Host Object can not be used with the current
baud rate
12h Invalid SPDU input size in start-up telegram
13h Invalid SPDU output size in start-up telegram
14h Badly formatted input SPDU
15h Anybus CompactCom to safety module initialization failure
