Anybus CompactCom 40 EtherNet/IP User Manual

167
Doc.Id. HMSI-27-212
Anybus CompactCom 40 EtherNet/IP
Doc.Rev. 1.5
Command Details: Set_Configuration_Data
Category
Extended
Details
Command Code: 11h
Valid for: Object Instance
Description
If the data segment in the CIP ‘Forward_Open’ service contains Configuration Data, this will be for-
warded to the host application through this command. If implemented, the host application should eval-
uate the request and return a proper response.
Segmentation is used, see “Message Segmentation” on page 189 for more information. The maximum
total amount of configuration data that will be accepted by the module is 458 bytes.
Note: This command must be implemented in order to support Configuration Data. If not implement-
ed, the CIP ‘Forward_Open’-request will be rejected by the module.
• Command Details
• Response Details (Success)
• Response Details (Error)
Field Contents Notes
CmdExt[0] - (reserved, ignore)
CmdExt[1] Segmentation Control bits See “Message Segmentation” on page 189
MsgData[0 - 1]
a
a. MsgData[0 - 1]and MsgData[2 - 3] can both be 0. Normally, the Set_Configuration_Data command is sent to the
application when an I/O connection is setup on the network. Producing connection point and consuming connec-
tion point are available and will be forwarded with the command. But if the configuration data originates from a set
attribute single request or a not matching NULL forward open request, there is no information on the connection
points and 0 (zero) will be forwarded to the application.
Producing connection point Producing connection point, requested by the originator.
MsgData[2 - 3]
a
Consuming connection point Consuming connecition point, requested by the originator.
MsgData[0... n] Data Actual configuration data
Field Contents Notes
CmdExt[0] 00h (reserved, set to zero)
CmdExt[1] 00h (reserved, set to zero)
Field Contents Notes
CmdExt[0] 00h (reserved, set to zero)
CmdExt[1] 00h (reserved, set to zero)
MsgData[0] Error code Anybus error code
MsgData[1] Extended error code If the Anybus error code is set to FFh, the extended error
code shall be translated as shown in “Extended Error
Code” on page 168.
MsgData[2 - 3] Index If the Extended error code is set to 02h (invalid configura-
tion), this parameter points to the attribute that failed.
