POS MV V4 User Guide
System Configuration
Copyright © Applanix Corporation, 2009
4-12
Set the initial configuration of POS MV by performing the following.
a) Connect the PCS and the controlling PC to the 10/100BaseT Ethernet
LAN. Both must have compatible IP addresses; if necessary refer to
the
Changing Address description on page 4-8 for instructions on IP
addressing.
b) Power-on the PCS and the controlling PC, and start Microsoft
Windows™; from windows, launch the MV-POSView Controller
program.
c) Select Tools, Connect on the MV-POSView main window menu bar.
Configuration Data
To configure the POS MV consult the list of installation parameters that was
created as you progressed through the physical installation. Refer to the
Installation Parameters description starting on page 2-38 for detailed
instructions.
Configuration - Initial
Note: Select the standby mode prior to changing lever arm or mounting angle
values.
From the menu bar of the MV-POSView Controller program, select Settings,
Installation, Lever Arms & Mounting; the Lever Arms & Mounting Angles
tab is displayed (see
Figure 21). Use metres for lever arm distances and
degrees for misalignment angles.
In circumstances where you do not have the complete set of installation
parameters, you must at least enter values in the Ref. to IMU Lever Arm and
the Ref. to primary GNSS Lever Arm panes. This basic information allows
the system to supply useful data to the multi-beam sonar.
To Next Page
