IMU Interface
Do not disconnect the IMU cable while the PCS is powered-on.
Damage to the IMU or the PCS hardware may result.
The IMU data/power interface is a multi-pin female circular connector. Contact
Applanix for connection details or longer cables; refer to
Technical Support
and Service on page
A-1 for procedures.
P
HYSICAL INTERFACE
A double-shielded cable connects the IMU to the PCS. Ensure the cable is
secure by locking the connector shell to the base.
I/O Interface Connector - POS MV V4-1
The I/O connector supports a multi-connector breakout cable (I/O cable) that
permits access to the following signals:
• Two ports (one input and one output) for the One Pulse Per Second
(PPS) signal
• Five multi-function COM ports
• One (primary and secondary) GNSS receiver port for software
updates
• One analog port (optional)
• One Ethernet port
• Two Event input ports
Table 5 and Figure 9 provide the pin assignment for the I/O connector and pin
mapping of the I/O cable.
