POS MV V4 User Guide
Fault Identification
Copyright © Applanix Corporation, 2009
9-32
4. Disconnect GNSS antenna power and data cable at both GNSS and
PCS (
Figure 87 on page E-4).
5. Inspect cable and connectors for signs of damage or contamination.
Perform repairs to cable as necessary. Protect free ends of cable
from damage or contamination.
6. Replace cable if not repairable.
Replace
1. Connect GNSS antenna power and data cable at both GNSS (see
Figure 85 on page E-3) and PCS (Figure 87 on page E-4). Do not
over tighten. Protect free ends of cable from damage or
contamination.
2. Apply waterproof sealing tape or silicone sealant to protect TNC
antenna connector (see
Figure 85 on page E-3).
3. Replace power cable to PCS rear panel (starting page 9-26).
4. Observe PCS front panel power-on procedures (starting on page 4-
1).
POS Computer System
There are no user replaceable parts inside. Service shall be
performed by trained and qualified personnel. If you suspect a
fault condition with the PCS contact Applanix Custome
r
Support, refer to page A-1 for instructions.
To remove or replace the PCS complete this procedure.
Tools
• Cross tipped screwdrivers
Straight tipped screwdriver
