ANALOG I/O Port Configuration
The analog interface hardware option delivers motion measurements (roll,
pitch and heave) for use by an external multi-beam sonar equipment. Contact
your Applanix Customer Support representative for the details, see page
A-1.
Select Settings, Analog Port from the MV-POSView menu bar to display the
window shown in
Figure 27. This window allows you to change the
configuration of the ANALOG I/O port for use with multi-beam sonar
equipment.
Changes to the Scale Factors pane or any of the sense settings will not
appear on the main window Attitude pane because they apply only to the
ANALOG I/O port.
