File Size Control field (Ethernet Logging Control) - file size is
selectable; unlimited (1file), 64 MB or 128 MB; the file name
extensions are the same for all three cases
Command Buttons
Start Logging button (Ethernet Logging Control) - starts logging data;
the window stays open
Stop Logging button (Ethernet Logging Control) - stops logging data
and closes the file; the window stays open
OK button (all) - enables all window parameter settings and closes
the window, logging does not start
Close button (all) - closes the window without saving or enabling any
changes
Apply button (all) - enables all window parameter settings, but does
not close the window, logging does not start
To make the changes active when the PCS is next powered-on, select
Installation, Save Settings to save them to NVM.
The configuration for the Ethernet (LAN) data port affects only the PCS
output. Ethernet data logging is a function of the controlling PC and the MV-
POSView Controller program.
A change to the logged data groups may be made at any time, even when
logging is already in progress. The changes will take effect immediately when
you choose OK or Apply buttons on the Ethernet Logging Control window.
