Table 5: I/O Connector Pin Assignment - POS MV V4-1

I/O Cable

Mapping

I/O Pin Pin Description

PIN Connector

Signal

Type

Signal

Direction

32 COM 3 TX

RS-232 Output

33 COM 3 RX

RS-232 Input

34 COM 3 RTS *

RS-232 Output

35 COM 3 CTS

DB-9P

(male)

COM 3

Pin 5 = GND

RS-232 Input

36 GND

N/A

N/A N/A

37 COM 4 TX

RS-232 Output

38 COM 4 RX

RS-232 Input

39 COM 4 RTS *

RS-232 Output

40 COM 4 CTS

DB-9P

(male)

COM 4

Pin 5 = GND

RS-232 Input

41 GND

N/A

N/A N/A

42 GNSS 1 TX

RS-232 Output

43 GNSS 1 RX

RS-232 Input

44 GNSS 2 TX

RS-232 Output

45 GNSS 2 RX

DB-9P

(male)

Pin 5 = GND

RS-232 Input

46 Ethernet TX+

N/A Output

47 Ethernet TX-

N/A Output

48 Ethernet RX+

N/A Input

49 Ethernet RX-

RJ-45

(Socket)

Ethernet

N/A Input

50 I2C SCL N/A N/A

51 I2C SDA N/A N/A

52 I2C GND N/A N/A

53 I2C Chassis GND

DB-9P

(female)

Analog

(optional)

N/A N/A
