Ariens 921049 - Track Bearing Replacement; Remove Bearing from Left Side of Unit

EN – 58
14. Remove seals and flange bushings from gearcase.
See Figure 145.
Assemble Gearcase
See Figure 146.
1. Press rear seal into gearcase until flush with gearcase
exterior.
IMPORTANT: DO NOT press right seal into gearcase.
2. Reinstall right and rear flange bushings.
See Figure 147.
IMPORTANT: Gear is symmetrical and may be installed in
any orientation.
3. Install gear.
Figure 145
Figure 146
1. Seal
2. Flange Bushing
1
2
2
Figure 147
