EN – 61
See Figure 155.
16. Wrap seal protector around each auger shaft end so
holes in shaft are covered.
NOTICE: Unprotected seals can be damaged when
installed over rough edges in shaft, such as holes.
17. Install gearcase seals over seal protectors and press
into gearcase until each seal is flush with gearcase
exterior.
18. Remove seal protectors.
19. Turn auger shaft by hand to ensure shaft rotates
easily.
20. Reinstall bushing retainer into flange bushing groove.
See Figure 156.
See Figure 157.
21. Reinstall gearcase gasket.
22. Secure cover to gearcase with four external tooth
locking washer bolts.
