CS175-275-575-875 Installation Guide 67
Location 36 Zone type, zones 1 to 8 (eight segments, ND)
Zones can be programmed to be one of twenty different zone types (configurations).
Segment 1 corresponds to zone 1, segment 8 corresponds to zone 8.
The default zone types are listed below. These zone types can be customised by
programming group characteristics in locations 130 to 206.
Data Description of default zone types Data Description of default zone types
1
Burglary (“A” alarm)
11
Burglary (“B” alarm)
2
24-hour
12
Double knock (“B” alarm)
3
Double knock (“A” alarm)
13
Access (“B” alarm)
4
Access (“A” alarm)
14
Entry / Exit (“B” alarm)
5
Entry/Exit (“A” alarm)
15
Roller switch (“B alarm)
6
Keyswitch
16
TBD
7
Fire
17
TBD
8
Personal attack
18
TBD
9
Tamper
19
TBD
10
Roller switch (“A” alarm)
20
TBD
"
Roller switch zones can be used on the CSx75 control panel only. They cannot be used
on a CS216 hardware zone expander.
Location 37 Partition select, zones 1 to 8 (eight segments, FSD)
This location is used to select the partition(s) in which zones 1 to 8 reside. A zone may
reside in any combination of the eight partitions.
"
If a burglary zone resides in more than one partition, it is active only when all partitions in
which it resides are armed. A zone that resides in more than one partition is reported to
its lowest partition number.
Location 37 has eight segments. Segment 1 corresponds to zone 1 and segment 8
corresponds to zone 8.
Segment 1- 8 1
Partition #1
2
Partition #2
3
Partition #3
4
Partition #4
5
Partition #5
6
Partition #6
7
Partition #7
