80 CS175-275-575-875 Installation Guide
8
On: DTMF.
Location 127 SIA code group 1 (one segment, ND)
This location contains the event code sent for a Group 1 SIA or Contact ID report. See
Appendix 2
for a list of event codes. The zone ID refers to the zone in alarm.
Location 128 4/2 alarm code group 1 (three segments, ND)
This location contains the event code sent for a 4+2 report for Group 1. The zone ID refers
to the zone in alarm.
Segment 1
Report code 10’s digit.
Segment 2
Report code 1’s digit/Fast Format 8 channel number.
Segment 3
Voice channel reported for this event.
Location 129 4/2 restore group 1 (two segments, ND)
This location contains the restore code sent for a 4+2 report for Group 1. The zone ID
refers to the zone in alarm.
Segment 1
Report code 10’s digit.
Segment 2
Report code 1’s digit/Fast Format 8 channel number.
Location 130 Group 1 zone type characteristics (five segments, FSD)
This is a default zone type and should be changed only if you are certain about what you
are doing.
Segment 1 1
Fire (turn on for a fire zone).
2
24-hour (turn on for a non-fire 24-hour zone).
3
Keyswitch zone (normally open switch).
4
Follower/Access zone (turn on for a burglary zone that is instant
during non-entry times).
5
Delay 1 zone (follows timer 1 entry and exit times).
6
Delay 2 zone (follows timer 2 entry and exit times).
7
Interior (turn on if the zone should automatically bypass or
bypass for stay arming).
8
Local only (turn on if the zone should not be reported).
Segment 2 1
On: the zone type beeps the keypad for alarm.
2
On: the zone type sounds the yelping siren for alarm.
3
On: the zone type sounds the temporal siren for alarm.
4
On: the zone type chimes.
5
On: the zone type can be bypassed.
