ARRI Arriflex 435 Advanced User Manual

63
Displaying the Angle of the Mirror Shutter
(Mode 1)
• As long as the “PHASE”-button is depressed while in
standby, the set angle of the mirror shutter appears in
the upper display line.
The camera runs at inching speed.
Setting the shutter angle: see Chapter 5 .
Configuring Mode 1
On the ARRIFLEX 435ES a constant display of the shutter
angle can be configured in Mode 1:
• Depress the “SEL”-button repeatedly until the upper
display line blinks.
• The “SET”-button switches between film counter and
shutter angle.
Frame Rates
The ARRIFLEX 435 Advanced offers the possibility to set
and store two frame rates. It is possible to select and store:
• a standard frame rate (23.976, 24, 25, 29.97 and
30 fps),
• and a freely programmed frame rate
in increments of 0.001 fps for frame rates up to 100
fps and above 100 fps in increments of 0.01 fps.
The frame rate is activated via the “NORM/PS”-switch
➪ photo on the left of the camera. The “NORM”-position
corresponds to the standard frame rate, the “PS/CCU”-
position to the freely programmed frame rate.
Camera Operation
“PHASE”-button
“NORM/PS”-switch
