Installing the Touchscreen
18 FastPak EXP Operating Manual
3. If you are using the support arm, secure this arm
to the mounting bracket using the hardware
provided, as shown in Figure
2-2.
Figure 2-2 Securing the touchscreen support
arm to the mounting bracket
4. Secure the touchscreen to the mounting hardware
using the hardware provided, as shown in Figure
2-3.
