needed to connect.
1PPS
Output the PPS synchronization signal.
DBG
The DBG port is used for debug.
WAN
The WAN port allows you to connect an Ethernet cable to establish
communication between NR xCell 46116A and switch/router.
DC IN
The 12V DC Power port is used to power NR xCell 46116A when
connected to the AC power adaptor. Use only the provided power
adapter, as using any other power adapter may damage NR xCell
46116A
ANT1
ANT1 for External 3.3-5GHz 5G antenna connection
ANT2
ANT2 for External 3.3-5GHz 5G antenna connection
The equipment is to be connected only to PoE networks without routing to the outside plant
The equipment with a GPS function has not been evaluated for "life-safety" and "non-life-
safety" applications.
External antenna ports ANT1/ANT2 are disabled via software for this model and is not
modifiable by any third-party / end-user
