ASKEY COMPUTER CORPORATION

Chapter 3. The Askey 5G NR Small Cell Admin Website

NR xCell 46116A User Guide 59

3.6 About

3.6.1 GPS

This Askey 5G NR Small Cell GPS Page shows the GPS status, including GPS Satellite ID, signal quantities,

description, etc.

Figure 52. The Askey 5G NR Small Cell GPS Page
