Chapter 3. The Askey 5G NR Small Cell Admin Website
NR xCell 46116A User Guide 40
Copyright © 2023, All Rights Reserved.
Items
Descriptions
SST
Slice/Service Type, refers to the expected Network Slice behavior in terms of features and services
SD
Slice Differentiator, complements the SST to differentiate amongst multiple Network Slices of the
same SST. The SD value can be disabled for the standardized S-NSSAI that has only SST.
NR Band
Frequency bands for 5G New Radio. It supports the N48, N77
Physical Cell ID
Physical Cell identifier, is used to distinguish cells on the radio side. The value must be small than
512.
Uplink Layer
The channel over which a symbol on the antenna port is conveyed can be inferred from the
channel over which another symbol on the same antenna port is conveyed.
UL Dmrs-AdditionalPosition
Position for additional demodulation reference signal (DMRS) in uplink.
QRxLevMin
Minimum required RX level in the cell (dBm)
QQualMin
Minimum required quality level in the cell (dB)
If the device supports the NR Band 48, the SAS Provider item will display in the CU configuration as the
NR band is modified to 48.
Figure 38. The Askey 5G NR Small Cell DU Configuration – Bandwidth Profile
Figure 39. The Askey 5G NR Small Cell DU Configuration – SAS Provider
