Askey NR xCell 46116A

To Previous Page

Chapter 4 The Askey 5G NR Small Cell Support Utilities

NR xCell 46116A User Guide 68

5G Sub6G Band N77, 40MHz Bandwidth

NR ARFCN Profile

3.75G

4.05G

DL Earfcn

649896

670008

UL Earfcn

649896

670008

DL CenterFreq

3748440

4050120

UL CenterFreq

3748440

4050120

DL AbsArfcnPointA

648624

668736

UL AbsArfcnPointA

648624

668736

DL AbsFreqPointA

3729360

4031040

UL AbsFreqPointA

3729360

4031040

AbsArfcnSsb

649152

669312

AbsFreqSsb

3737280

4039680
