• an open door will not close, if the OPD detects activity in the field
• during opening, the door will continue to open, even if the OPD detects activity in the field
• during closing, the door will continue to close, even if the OPD detects activity in the field
• the OPD is not active in program mode OFF, manually opened door or during battery operation
(Power Save Mode).
5.3.7 Mat
Mat safety means that:
• a closed door will not open, if someone steps on the mat
• an open door will not close, if someone steps on the mat
• during opening, the door will continue to open, even if someone steps on the mat
• during closing, the door will continue to close, even if someone steps on the mat
• opening impulses are prevented during closing, if someone steps on the mat
• the mat is not active in program mode OFF, manually opened door or during battery operation
(Power Save Mode).
5.4 Functions on the extension unit EXU-SI
Also see page 46 for more information.
5.4.1 KILL function
• If KILL circuit is closed, the control will ignore all signals and close door(s) at normal speed.
• When KILL is no longer active, operator will resume normal operation.
• If KILL function must have manual reset, jumper must be removed and reset button connected
to terminal No. 8 and Ground.
• The lock will lock when KILL is active regardless of program selector setting.
• The function of the lock can be changed during KILL (see page 58).
• In a double door application, KILL is only connected to the primary operator.
5.4.2 Function of locks
• The lock output is short circuit proof and can source a lock with 12 V DC, max. 500 mA or 24 V
DC, max 250 mA. Lock function is active in programme selection EXIT and OFF
• DIP-switch to select 12 or 24 V DC
• DIP-switch to select locked with or without power
• DIP-switch for lock release and potentiometer for opening delay
• DIP-switch for lock kick if door is not fully closed, to overcome binding in the locking device
during closing
• Input to unlock signal from lock. Potentiometer for opening delay is to be set to max. As soon
as unlock signal is received the door will start to open. The output signal shall be active low.
5.4.3 Program selector
• Input for OPEN, EXIT and OFF (if no program selector, AUTO is default).
5.4.4 Impulses
• Input for OUTER impulse, KEY impulse and OPEN/CLOSE impulse.
1005088-en-22.0Issue 2021-02-2412
5 How the ASSA ABLOY SW100 works
