Assa Abloy SW100 User Manual

7.10 Extension units
For installation see page 45.
EXU-SA (kit for safety functions)
Art. No. 1003557
8 9 10
1 2 3 4 5
6 7
EXU-SI (kit for security functions)
Art. No. 1003554
1 2 3 4 5 6 7 8 9 10 11 12 13
1
ON
2 3 4 5
0.5 s
0 s
3 s
AIU (Audible warning signal)
Art. No. 656083
24 V DC
ILL-01887
7.11 Battery backup unit
Note! Disconnect mains when replacing battery.
Risk of explosion if wrong type of bat-
tery is used.
Art. No. 1003567
7.12 Cover piece kit
Art. No.: 1009935BK/SI
1005088-en-22.0Issue 2021-02-2426
