Assa Abloy SW100 User Manual

6 Models
Three main models of the ASSA ABLOY SW100 are available:
• ASSA ABLOY SW100, standard cover
• ASSA ABLOY SW100-SPEC, cover with optional length
• ASSA ABLOY SW100-2, double door operators
The operators are non-handed and not dependent on the hinges. The operators suit both pushing
and pulling arm systems.
6.1 ASSA ABLOY SW100, standard cover (wall mounted)
ASSA ABLOY SW100 is the standard operator. Pushing arm system shown. Measurement from
hinge centerline to outgoing shaft is always 210 mm regardless if butt or pivot hinged systems.
ILL-01608
716
40 210
1005088-en-22.0Issue 2021-02-2416
6 Models
