8.5 Tools required
• Torx T10
• Metric Allen wrenches 2,5; 3; 4 and 6 mm
• Flatblade screwdriver (potentiometer and terminal size)
• Screwdriver (Philips size 2)
• Nut driver, 5 mm
• Carpenter’s level
• Tape rule
• Power drill and set of drill bits
• Center punch
• Wire stripper
• Silicone sealant
• Installation and Service Manual (this manual)
8.6 Installation on double doors
If the operators are to be mounted at the same height with pushing and pulling arm systems, the
height is determined by the pulling arm system, PULL. The pushing arm system PUSH must always
have a shaft extension, minimum 50 mm, maximum 70 mm to match the mounting heights visually.
Example: if PULL has a 20 mm extension, the PUSH must have a 70 mm extension. If PULL has 0 mm
extension, the PUSH must have a 50 mm extension.
1005088-en-22.0Issue 2021-02-2430
8 Pre-installation
