This product is to be installed internally.
65
130
38 3834
7518
110
4.1 Permitted door weight and door width
0
50
100
150
200
250
300
350
400
450
0.8 0.9 1 1.1 1.2 1.3 1.4
PUSH arm
PULL arm
J=45 kgm²
J=16 kgm²
PUSH arm
PULL arm
Door weight (kg)
Door width (m)
1005088-en-22.0Issue 2021-02-2410
4 Technical specifications
