Associated Research 620L User Manual

18
GENERAL
Safety Agency Listing
CE, cTUVus, RoHS2
PLC Remote Control
Input - Test, Reset, Interlock, and Recall
Memory 1 through 10 (4Bits)
Output – Pass, Fail, Test-in-Process, Start-Out,
Reset-Out
Memory
50 files, 30step/file.
File locations can be linked.
900 connected steps maximum.
Display
320 X 240 graphic LCD
LCD Contrast Setting
Adjustable
Alarm Volume Setting
Adjustable
Security
Lockout capability to avoid unauthorized access
to test set-up programs.
Security Password.
Interface
USB/RS-232 standard
Dimension
430 (W) x 133(H) x 300 (D) mm
Weight
12 Kg
GFI on DUT input power
Trip current = 5mA ± 10%
POWER METER
W
Range: 0-1KW / 1-10KW Resolution: 0.1W/1W,
A
0.0 – 3.500 A / 3.00 - 40.00A
Resolution: 0.001A / 0.01A
PF
0.000 -1.000
LA
Range:
0.0 -10.00 mA
Resolution:
0.01mA
Accuracy :
± (2 % of reading + 2
counts)
AC Current High/Low Limit Setting
Range:
0-40A
Resolution:
0.01A/step
AC Current Display
Range 1:
0.000 – 3.500 A
Resolution:
0.001A
Accuracy :
± (2 % of reading + 5
counts)
AC Current Display
Range 2:
3.00 - 40.00A
Resolution:
0.01A
Accuracy :
± (2 % of reading + 2
counts)
AC Power High/Low Limit Setting
Range:
0 - 10KW
Resolution:
1W
AC Power Display
Range:
0-1000W / 1000 - 10000W

Associated Research 620L Specifications

General

Brand	Associated Research
Model	620L
Category	Test Equipment
Language	English
