Associated Research 620L - Page 87

81
RUN
LLT
1
Voltage-HI
Leakage-HI
2
Voltage-LO
Leakage-LO
3
Amp-HI
Voltage-HI
4
Amp-LO
Voltage-LO
5
Dwell Time
Delay Time
6
Delay Time
Neutral (OPEN/CLOSED)
7
Leakage-HI
Reverse (ON/OFF)
8
Leakage-LO
Ground (OPEN/CLOSED)
9
Power-HI
Meas. Device
(UL544NP/UL544P/IEC60601
UL2601/UL1563/IEC60990 FIG4-
U2, IEC60950/IEC60990 FIG5-
U3/EXTERNAL)
10
Power-LO
Probe
(Ground To Line/ Probe-HI to
Line/Probe-HI To Probe-LO)
11
PF-HI
Leakage Mode (Peak/RMS)
12
PF-LO
Extended Meter (ON/OFF)
13
Continuous (ON/OFF)
AC/DC (AC+DC,AC,DC)
14
Ranging Mode (AUTO, MANUAL)
15
Continuous (ON/OFF)
16
Scanner
SAR, SAL
These commands insert or add a new step to the test sequence. This command will
add or insert the test at the step location that has been selected. When a test has
already been created at a selected step then the new step will be inserted and the
previous step will move down to the next step and all other step will be renumbered
accordingly. See the command summary tables to see the specific test type for each
of these commands.
SD
Deletes the active step from the setup file sequence. All step after this step will move
up and be renumbered accordingly.
SD <step number>
Deletes the step indicated by the number from the setup file sequence. All step after
this step will move up and be renumbered accordingly.
SP <prompt message>
Adds or edits a prompt message for the active step.
SP
Removes or deletes the prompt that had been created for the active step.
