Chapter 2 – Hardware Information 9
Maker Board UP Xtreme UP-WHL01
2.3 List of Jumpers and Connectors
Please refer to the table below for all of the board’s jumpers that you can configure for
your application
Label
Function
SW2
PWR button
CN1
RTC
CN2
MINI-CARD
CN3
M.2_2230_E-KEY
CN4
M.2 SLOT_M key
CN5
SATA Connector
CN6
SATA POWER
CN7
LAN1
CN8
LAN2
CN10
HDMI/DP
CN11
DOCKING I
CN13
eDP
CN14
USB Type A Connector 1
CN15
USB Type A Connector 1
CN16
USB 2.0 1x10P Wafer
CN19
FAN
CN20
DC JACK
CN22
HAT 40
CN24
AUDIO JACK
CN25
ADUINO
CN26
DOCKING II
