Page #14 background image
Chapter 1 Product Specifications 2
Maker Board UP Xtreme UP-WHL01
1.1 Specifications
System
CPU
Intel® WHL-UE (Core i3/5/7 Ultra Low Power -
15 W)
Intel® Celeron™ 4305UE (up to 2.0 GHz)
Memory
Onboard Single/Dual Channel DDR4 memory,
Max 16GB
Graphics
Intel® Graphics , GEN 9
Display Out
HDMI 2.0 x1 (CEC support)
DP 1.2 x 1
eDP x 1
Storage
eMMC ver 5.1 (64GB)
SATA3 (6Gb/s) x 3:
- SATA connector x 1
- M.2 2280 SATA (auto-detect) x 1
- Minicard mSATA (auto-detect) x 1
Ethernet
1x Intel i210/ Intel i211 (optional)
1x i219LM PHY
Audio
HDMI Audio x 1
DP Audio x 1
ALC887 for Audio Out/Mic In
I2S
USB
USB 3.0 x 4
USB 2.0 x 1
COM Port
Fintech F81801, RS232/422/485 x 2
