Asus AAEON UP Xtreme UP-WHL01 User Manual

Chapter 1 – Product Specifications 3
Maker Board UP Xtreme UP-WHL01
System
Expansion Slot
Minicard x 1 (PCIe [x1] Gen 3 x 1 (mSATA
optional), USB 2.0 x 1) with SIM card
M.2 2230 E Key x 1 (PCIe [x1] Gen 3 x 1, USB 2.0
x 2, CNVI x 1)
M.2 2280 (double fixing hole) B/M Key x1 (PCIe
Gen 3 x 2 / SATA x 1)
Expansion HAT (40pin)
By MAX5:
- GPIO x 28
- SPI x 2
- I2C x 2
- ADC x 1
- I2S x 1
- PWM x 2
- UART x 1
- 3V3
- 5V
- GND

Asus AAEON UP Xtreme UP-WHL01 Specifications

General

Brand	Asus
Model	AAEON UP Xtreme UP-WHL01
Category	Motherboard
Language	English
