Chapter 2 – Hardware Information 11
Maker Board UP Xtreme UP-WHL01
2.3.2 RTC (CN1)
Pin
Signal
1
RTC_VCC
2
GND
2.3.3 Mini-Card (CN2)
Pin
Signal
Pin
Signal
1
WAKE_MINI_N
2
VCC3_MINIPCIE
3
NC
4
GND
5
NC
6
V1.5S
7
NC
8
P_UIM_PWR
9
GND
10
P_UIM_DAT
11
PCIE_REFCLK5_P2_N
12
P_UIM_CLK
