Asus AAEON UP Xtreme UP-WHL01 User Manual

CEC Client Installation 36
CEC Client Installation Supplemental Appendix for UP Xtreme
OpCode
Value
Description
Parameters
Response
Supported
<Record
On>
0x09
Attempt to
record the
specified source.
[Record
Source]
Enter ‘Recording’
state and start
recording if possible.
Send the initiator
<Record Status>.
Yes
<Record
Status>
0x0A
Used by a
Recording
Device to inform
the initiator of
the message
<Record On>
about its status.
[Record
Status Info]
Yes
5.1.5 Timer Programming
Command Feature: This feature allows a device (e.g. TV) to set a timer recording on a
Recording Device. For example, it can be used to set timer blocks of a Recording
Device via a TV menu or via an EPG.
The following messages are used for the Timer Programming feature: <Clear
Analogue Timer>, <Clear Digital Timer>, <Clear External Timer>, <Set Analogue
Timer>, <Set Digital Timer>, <Set External Timer>, <Set Timer Program Title>, <Timer
Cleared Status>, <Timer Status>.
OpCode
Value
Description
Parameters
Response
Supported
<Clear
Analogue
Timer>
0x33
Used to clear an
Analogue timer
block of a
device.
See <Set
Analogue
Timer>
message.
Clear timer block if
possible, then
respond with
<Timer Cleared
Status>
Yes
<Clear
Digital
Timer>
0x99
Used to clear a
Digital timer
block of a
device.
See <Set
Digital Timer>
message
Clear timer block if
possible, then
respond with
<Timer Cleared
Status> message
Yes
<Clear
External
Timer>
0xA1
Used to clear an
External timer
block of a
device
See <Set
External
Timer>
message
Clear timer block if
possible, then
respond with
<Timer Cleared
Status> message
Yes
Table Continues on Next Page
