Appendix B – Cables and Connectors 40
Maker Board UP Xtreme UP-WHL01
B.1 Cables and Connectors
This table provides detailed information about the cables and connectors used by the
UP Xtreme (UP-WHL01). If you have any questions about the configuration of your
board, please contact your AAEON sales representative.
Connector
Label
Connector PN
Description
Mating Cable
PN
Mating Cable
Description
CN1
1655902034
RTC Battery
Connector
175011301K
Lithium
Battery.CR2032H.3V.2
40mAH.w/cable
90mm. DIP.Battery
power.BP-CR2032-M9
0-001
CN2
1654226303
mini-PCIe (PCIe x1)
N/A
CN3
1654207533
m.2 2230 E Key
N/A
CN4
165420753B
m.2 2280 M/B Key
N/A
CN5
1654907009
SATA
N/A
CN6
1655302025
SATA Power (DC 5V)
N/A
CN7
1652814207
GbE RJ-45
N/A
CN8
1652814207
GbE RJ-45
N/A
CN10
1654403931
HDMI 2.0 + DP 1.2
N/A
CN13
1654904130
eDP Connector
N/A
CN11
1654010006
100-pin Docking
Connector
N/A
CN14
1654801832
2x USB 3.1 Gen2
(10Gbps)
N/A
CN15
1654801832
2x USB 3.1 Gen2
(10Gbps)
N/A
CN16
1655810131
10-pin USB
2.0+HSUART
Connector
N/A
CN19
165500401A
CPU Smart Fan
Connector (3-pin)
175920001F
CPU Cooler.Fan+Heat
Sink.12V.3P.for UPWH
