Appendix B – Cables and Connectors 41
Maker Board UP Xtreme UP-WHL01
Connector
Label
Connector PN
Description
Mating Cable
PN
Mating Cable
Description
CN20
165250320K
12 ~ 60 VDC Input
(Lockable, OD/ID:
5.1/2.5 mm)
N/A
CN22
165302020L
40-pin HAT
Connector
N/A
CN25
1655840030
STM32 I/O Header
N/A
CN26
1653215200
STM32 I/O Header
N/A
COM1
1655901000
10-pin
RS-232/422/485
Header
1701100180
COM Cable.D-SUB
9P(M).10P.1.0mm
Housing.15cm
COM2
1655901000
10-pin
RS-232/422/485
Header
1701100180
COM Cable.D-SUB
9P(M).10P.1.0mm
Housing.15cm
SIM1
1654900800
Micro-SIM Card Slot
N/A
SW2
1601615600
Power Button with
LED
N/A
