CEC Client Installation 38
CEC Client Installation Supplemental Appendix for UP Xtreme
OpCode
Value
Description
Parameters
Response
Supported
<Set Timer
Program
Title>
0x67
Used to set the
name of a
program
associated with
a timer block.
Sent directly
after sending a
<Set Analogue
Timer> or <Set
Digital Timer>
message. The
name is then
associated with
that timer block.
[Program Title
String]
Recording device
stores title for
future reference.
Ignore message if
it is not the
immediate next
message from this
initiator following
a <Set Analogue
Timer> or <Set
Digital Timer>
message.
Yes
<Timer
Cleared
Status>
0x43
Used to give
the status of a
<Clear
Analogue
Timer>, <Clear
Digital Timer>
or <Clear
External Timer>
message
[Timer Cleared
Status Data]
If the message
indicates that the
timer was not
cleared because
there was no
matching entry,
the device should
remove the timer
block locally.
Yes
<Timer
Status>
0x35
Used to send
timer status to
the initiator of a
<Set Timer>
msg
[Timer Status
Data]
None
Yes
5.1.6 System Information
Command Feature: This feature allows devices to automatically use the same OSD and
Menu language settings as the TV and also for a TV to discover the current language
when it is being installed.
The following messages are used for the System Information feature: <CEC Version>,
<Get CEC Version>, <Get Menu Language>, <Give Physical Address>, <Polling
Message>, <Report Physical Address>, <Set Menu Language>.
Table on Next Page
