Asus AAEON UP Xtreme UP-WHL01 User Manual

CEC Client Installation 39
CEC Client Installation Supplemental Appendix for UP Xtreme
OpCode
Value
Description
Parameters
Response
Supported
<CEC
Version>
0x9E
Used to indicate the
supported CEC
version, in response
to a <Get CEC
Version>
[CEC
Version]
Yes
<Get CEC
Version>
0x9F
Used by a device to
enquire which
version of CEC the
target supports
None
The source
responds with a
<CEC Version>
Message
indicating the
CEC version
Yes
<Give
Physical
Address>
0x83
A request to a
device to return its
physical address.
None
<Report
Physical
Address>
Yes
<Get Menu
Language>
0x91
Sent by a device
capable of character
generation (for OSD
and Menus) to a TV
in order to discover
the currently
selected Menu
language. Also used
by a TV during
installation to
discover the
currently set menu
language of other
devices.
None
The addressed
device responds
with a <Set
Menu
Language>
message
Yes
<Polling
Message>
—
Used by any device
for device discovery
– similar to ping in
other protocols.
None
Shall set a low
level ACK.
Yes
<Report
Physical
Address>
0x84
Used to inform all
other devices of the
mapping between
physical and logical
address of the
initiator.
[Physical
Address]
[Device
Type]
Yes
<Set Menu
Language>
0x32
Used by a TV or
another device to
indicate the menu
language.
[Language]
Set the menu
language as
specified, if
possible.
Yes
