CEC Client Installation 34
CEC Client Installation Supplemental Appendix for UP Xtreme
5.1.1 One Touch Play
Command Feature: The One Touch Play feature allows a device to be played and
become the active source with a single button press.
The following messages are used for the One Touch Play feature: <Active
Source>, <Image View On>, <Text View On>.
OpCode
Value
Description
Parameters
Response
Supported
<Active
Source>
0x82
Used by a new
source to indicate
that it has started
to transmit a
stream OR used
in response to a
<Request Active
Source>
[Physical
Address]
A current active source
should take
appropriate Action. TV
should switch to the
appropriate input. Any
CEC switches between
source and root shall
switch to the
appropriate input and
come out of standby if
necessary.
Yes*
<Image
View
On>
0x04
Sent by a source
device to the TV
whenever it
enters the active
state
(alternatively it
may send <Text
View On>).
None
Turn on (if not on). If in
‘Text Display’ state than
the TV enters ‘Image
Display’ state. Note:
Should not change TV
menu or PIP status.
Yes
<Text
View
On>
0x0D
As <Image View
On>, but should
also remove any
text, menus and
PIP windows from
the TV’s display.
None
As <Image View On>,
but should remove PIPs
and menus from the
screen. The TV enters
‘Image Display’ state
regardless of its
previous state.
Yes
*See Chapter 5.1 for limitations.
