Asus AAEON UP Xtreme UP-WHL01 User Manual

Chapter 2 – Hardware Information 12
Maker Board UP Xtreme UP-WHL01
Pin
Signal
Pin
Signal
13
PCIE_REFCLK5_P2_P
14
P_UIM_RST
15
GND
16
P_UIM_VPP
17
NC
18
GND
19
NC
20
3G_EN
21
GND
22
3G_RST
23
PERN0_MSATA_R+
24
VCC3_MINIPCIE
25
PERP0_MSATA_R-
26
GND
27
GND
28
V1.5S
29
GND
30
NC
31
PETN0_MSATA_T-
32
NC
33
PETP0_MSATA_T+
34
GND
35
GND
36
USB2_DN_R
37
GND
38
USB2_DP_R
39
VCC3_MINIPCIE
40
GND
41
VCC3_MINIPCIE
42
NC
43
MSATA_PCIE_SEL_C
44
NC
45
NC
46
NC
47
NC
48
V1.5S
49
NC
50
GND
51
NC
52
VCC3_MINIPCIE
