Asus AAEON UP Xtreme UP-WHL01 User Manual

Chapter 1 – Product Specifications 4
Maker Board UP Xtreme UP-WHL01
I/O
Internal I/O Connectors
eDP with Backlight control Header x 1
10 pin x 1 for USB 2.0 x 1 / HSUART (TTL) x 1
SATA Connector with power connector x 1
4 pin Fan connector x 1
Power Button header x 1
Reset Pin header x 1
M.2 2230/ E Key x 1
M.2 2280 B+M Key x 1
40 pin HAT connector x 1
10 pin RS232/422/485 pin header x 2
100pin expansion connector x 1
External I/O Connectors
RJ45 Ethernet Connector x 2
HDMI/DP STACK Connector x 1
USB 3.0 STACK Connector for 2 ports (Front) x 1
USB 3.0 STACK Connector for 2 ports (Rear) x 1
Power Button / LED x 1
Audio Jack (Line out + MIC) x 1
DC connector (Lockable) x 1
Miscellaneous
Power
12~60V Input
Form Factor
120mm x 122mm
Operating Temperature
0°C ~ 60°C
Operating Humidity
0% ~ 90% relative humidity, non-condensing
Certification
CE, FCC
OS Support
Win 10, Linux (Ubuntu, Yocto), Android

Asus AAEON UP Xtreme UP-WHL01 Specifications

General

Brand	Asus
Model	AAEON UP Xtreme UP-WHL01
Category	Motherboard
Language	English
