Chapter 2 – Hardware Information 22
Maker Board UP Xtreme UP-WHL01
Pin
Signal
Pin
Signal
42
GND
92
SATA_LED_N
43
PCIE_TXP0
93
PLTRST_PNLBKLEN
44
PCIE_TXP1
94
NC
45
PCIE_TXN0
95
PCIE_WAKE0_N
46
PCIE_TXN1
96
PCIE_CLKREQ0#
47
GND
97
PCIE_WAKE1_N
48
GND
98
PCIE_CLKREQ1#
49
PCIE_REFCLK2_P
99
PCIE_WAKE2_N
50
PCIE_P3_TXP
100
PCIE_CLKREQ2#
