Page #39 background image
Chapter 2 – Hardware Information 27
Maker Board UP Xtreme UP-WHL01
Pin
Signal
Pin
Signal
13
ANALOG_DATA3
14
GND
15
ANALOG_DATA4
16
SPI1_CS1
17
3.3V
18
SPI1_RX
19
SPI0_TX
20
GND
21
SPI0_RX
22
SPI1_TX
23
SPI0_CLK
24
SPI0_CS0
25
GND
26
SPI0_CS1
27
I2C0_DAT
28
I2C0_CLK
29
GPIO
30
GND
31
SPI1_CLK
32
PWM0
33
PWM1
34
GND
35
I2S_WS_SYNC
36
UART_CTS
37
SPI1_CS0
38
I2S_SDI
39
GND
40
I2S_SDO
