Chapter 2 – Hardware Information 29
Maker Board UP Xtreme UP-WHL01
Pin
Signal
Pin
Signal
9
STM32_PB6
10
STM32_PB9
11
STM32_PB5
12
STM32_PC15
13
STM32_PB4
14
MCU_NRST_R
15
STM32_PB3
16
MCU_WKUP_R
17
USB_RENUMn
18
STM32_PA1
19
SWDCLK_R
20
STM32_PA2
21
SWDIO_R
22
STM32_PA3
23
NC
24
STM32_PA4
25
NC
26
STM32_PA5
27
STM32_PA10
28
STM32_PA6
29
STM32_PA9
30
STM32_PA7
31
STM32_PA8
32
HDMI1_CEC_D
33
STM32_PB15
34
STM32_PB2
35
STM32_PB14
36
HOST_I2C_SCL
37
STM32_PB13
38
HOST_I2C_SDA
39
MCU_INT_R
40
+V5S
