ATI Technologies Axia80-M20 User Manual

Manual, F/T Sensor, Ethernet Axia
Document #9610-05-Ethernet Axia-09
Pinnacle Park • 1031 Goodworth Drive • Apex, NC 27539 • Tel:+1 919.772.0115 • Fax:+1 919.772.8259 • www.ati-ia.com
30
Figure 4.4—Filter Attenuation at 4 kHz Sample Rate
-30.0 dB
-24.0 dB
-18.0 dB
-12.0 dB
-6.0 dB
0.0 dB
0 Hz 1 Hz 10 Hz 100 Hz 1000 Hz
2.7 Hz
4.7 Hz
10 Hz
20 Hz
40 Hz
84 Hz
180 Hz
460 Hz
1000 Hz
Frequency
Attenuation
Figure 4.5—Filter Attenuation at 8 kHz Sample Rate
-30.0 dB
-24.0 dB
-18.0 dB
-12.0 dB
-6.0 dB
0.0 dB
0 Hz 1 Hz 10 Hz 100 Hz 1000 Hz 10000 Hz
373 Hz
958 Hz
2000 Hz
935.10 Hz
364.04 Hz
169.52 Hz
81.24 Hz
39.84 Hz
20.31 Hz
9.37 Hz
5.47 Hz
Frequency
Attenuation
