ATI Series D12 Toxic Gas Transmitter with H10 Smart Sensor
Revision N (7/15) 65
System
System pages are used to access and configure the internal clock, security, reset functions,
communication protocols, and version information.
System Access
The System Access page provides links to the clock, security,
communications, and version pages (the Reset link has been removed
on transmitters beginning with version 2.23).
Figure 65. System access page
Real-time Clock
Clock Setup
The Clock Setup page is used to set the transmitters real-time clock,
which is referenced during sensor calibrations and data logging, and
used to trigger Auto-test.
Figure 66. Clock setup page
Day
Monday, Tuesday, Wednesday, Thursday, Friday, Saturday, and Sunday
Date
Used to configure the month, date, and year, in the format specified by the
Format variable (below). Built-in support for leap year.
Format
Selects the date format:
MM/DD/YY, example: 09/19/06
DDMMMYY, example: 09Sep06
Time
24-hour format, 00:00 to 23:59
►Clock Commun
Secure Version
Reset
>Menu >Setup >System
►Day= Tuesday
Date=09/17/06
Format=MM/DD/YY
Time=14:00
>Menu >Setup >System >Clock
