ATI Series D12 Toxic Gas Transmitter with H10 Smart Sensor
Revision N (7/15) 74
Table 22. Transmitter
Part No.
Description
03-0275 PCB Stack Assembly w/o Relays
03-0263 PCB Stack Assembly with Relays
03-0279 Remote PCB Stack Assembly w/o Relays
03-0280 Remote PCB Stack Assembly with Relays
03-0250 Connector Housing Assembly
03-0307 Connector Housing Assembly w/Heater
03-0246 Sensor/Generator holder
31-0162 Remote Interconnect Cable (25’ Standard)
03-0276 PCB Stack Assembly w/Rlys
80-0066 Transmitter explosion-proof housing
46-0003 Sensor gasket (non auto-test version)
46-0002 Sensor/generator gasket (auto-test version)
00-1056 Calibration adapter
00-1251 Flowcell Assembly
29-0007 Battery
55-0004 Magnetic Screwdriver
Table 23. H10 sensor modules
Part No. Description
00-1000 Bromine, 0-1/5 PPM (2 PPM Standard)
00-1001 Bromine, 0-5/200 (20 PPM Standard)
00-1002 Chlorine, 0-1/5 PPM (2 PPM Standard)
00-1003 Chlorine, 0-5/200 (20 PPM Standard)
00-1004 Chlorine dioxide, 0-1/5 PPM (2 PPM Standard)
00-1005 Chlorine dioxide, 0-5/200 (20 PPM Standard)
00-1006 Fluorine, 0-1/5 PPM (2 PPM Standard)
00-1007 Fluorine, 0-5/200 (20 PPM Standard)
00-1008 Ozone, 0-1/5 PPM (2 PPM Standard)
00-1009 Ozone, 0-5/200 PPM (20 PPM Standard)
00-1010 Ammonia, 0-50/500 PPM (200 PPM Standard)
00-1011 Ammonia, 0-500/2000 PPM (1000 PPM Standard)
00-1012 Carbon monoxide, 0-50/1000 PPM (200 PPM Standard)
00-1013 Hydrogen, 0-1/10% (4% Standard)
00-1014 Oxygen, 0-5/25% (25% Standard)
00-1015 Phosgene, 0-1/5 PPM (2 PPM Standard)
00-1016 Phosgene, 0-5/100 PPM (100 PPM Standard)
00-1017 Hydrogen chloride, 0-10/200 PPM (20 PPM Standard)
00-1018 Hydrogen cyanide, 0-10/200 PPM (20 PPM Standard)
00-1019 Hydrogen fluoride, 0-10/200 PPM (20 PPM Standard)
00-1020 Hydrogen sulfide, 0-10/200 PPM (50 PPM Standard)
00-1021 Nitric oxide, 0-50/500 PPM (200 PPM Standard)
00-1022 Nitrogen dioxide, 0-10/200 PPM (20 PPM Standard)
00-1023 Sulfur dioxide, 0-10/500 PPM (20 PPM Standard)
00-1024 Arsine, 0-500/2000 PPB (1000 PPB Standard)
00-1025 Arsine, 0-10/200 PPM (10 PPM Standard)
00-1026 Diborane, 0-500/2000 PPB (1000 PPB Standard)
00-1027 Diborane, 0-10/200 PPM (10 PPM Standard)
00-1028 Germane, 0-500/2000 PPB (1000 PPB Standard)
00-1029 Germane, 0-10/200 PPM (10 PPM Standard)
00-1030 Hydrogen selenide, 0-500/2000 PPB (1000 PPB Standard)
00-1031 Hydrogen selenide, 0-10/200 PPM (10 PPM Standard)
00-1032 Phosphine, 0-500/2000 PPB (1000 PPB Standard)
