ATI Series D12 Toxic Gas Transmitter with H10 Smart Sensor
Revision N (7/15) 72
Restart
The Restart function will cause the transmitter to start up, just as it does during a power-on-reset. This
function replaces the Reset page beginning with version 2.23 of the D12 Toxic Gas Transmitter.
Resets
Note: the Reset page has been removed on software versions 2.23, and higher.
The Reset page provides functions for resetting configuration memories, and restarting the transmitter,
which may prove useful for correcting specific faults. These functions should not be used unless they
are specified in troubleshooting procedures, or directed by authorized factory personnel.
Table 21. Reset functions (do not use except for troubleshooting).
Sensor
Resets zero and span calibration, restarts transmitter. Sensor must be completely
recalibrated. On LEL transmitters, calibration and Auto-test history are cleared.
Alarms
Resets alarm set/reset points, options, delays, and inhibit_mA, restarts transmitter.
4-20mA
Resets 4-20mA calibration, loop must be recalibrated, restarts transmitter.
DataLog
Clears the data log history, restarts transmitter.
All
Resets entire transmitter to factory defaults, excluding sensor, restarts transmitter.
Requires full transmitter setup.
Restart
Restarts transmitter, only.
Reset Functions
►Sensor DataLog
Alarms All
4-20mA Restart
>Menu>Setup>System>Reset
