ATI Series D12 Toxic Gas Transmitter with H10 Smart Sensor
Revision N (7/15) 77
Report Format
The format of the report is suitable for import into most spreadsheet programs and consists of a date
column, a time column, and 1-30 columns for sample values. Each line of the report shows the date
and time of the first sample. Samples appearing in subsequent columns (left to right) were recorded at
equal sampling intervals.
In the top line of the example below, the first sample (S0) occurred at 22:40. The next sample to the
right (S1) occurred at 22:41, followed by the next (S2) at 22:42, and so on. This pattern is repeated
throughout the report.
The transmitter permits selection of either a CR (carriage
return) or CR/LF (carriage return/line feed) as the EOL (end-
of-line) characters. If the lines of the report appear to be
printing over each other, choose the CR/LF option. If the
lines appear to be double spaced, choose the CR option.
The number of sample columns appearing across the page is
programmable from 1 to 30. This is designed so that a report
may be directed to either a small carriage printer, or to a
wider format device. A wider report will take less time to
print because the date and time fields will be printed less
frequently.
Samples reported are assumed to be in units of PPM, PPB,
%, or %LEL, as determined by the gas concentration units
appearing on the main display of the transmitter. Sample
values outside of printing limits are forced to the following
values.
Less than –999 -999
Greater than 9999 9999
Symbols may appear in place of sample values, and are defined as follows.
----
No sample recorded. The transmitter was not on to
record the sample, or has not yet recorded the sample.
FFFF
The transmitter was in fault during the sample.
TEST
The transmitter was in auto-test during the sample. This
symbol appears only if the Log_Data variable in the
Menu/Setup/Auto-T/Setup menu is set to “NO”.
****
Data in the log is corrupted or unreliable.
Report Control
The start date and length of the report may be controlled from the operator interface. The length of the
report is limited to the number of days actually stored in the log. The report always begins at 00:00 on
the start date, and continues forward for the number of days specified. If no data has yet been logged,
the report will show four dashes (----) in place of samples.
07/09/06 22:40 0.01 0.00 0.02 0.01
07/09/06 22:44 –0.0 0.00 0.00 –0.0
07/09/06 22:48 0.01 TEST TEST TEST
07/09/06 22:52 TEST TEST TEST TEST
07/09/06 22:56 TEST TEST TEST TEST
07/09/06 23:00 0.07 0.06 0.07 0.06
07/09/06 23:04 0.06 0.05 0.06 0.06
07/09/06 23:08 0.05 0.05 0.04 0.05
07/09/06 23:12 0.06 0.05 0.05 0.04
07/09/06 23:16 0.01 0.01 0.01 0.00
07/09/06 23:20 0.00 0.00 0.00 -0.1
07/09/06 23:24 –0.0 0.00 0.00 0.00
07/09/06 23:28 ---- ---- ---- ----
07/09/06 23:32 ---- ---- ---- ----
07/09/06 23:36 ---- ---- ---- ----
07/09/06 23:40 FFFF FFFF 0.02 0.02
Date Time
