ATI Series D12 Toxic Gas Transmitter with H10 Smart Sensor
Revision N (7/15) 82
Navigate to the DataLog page and select Print. You will not be allowed access if there are no samples
in the log.
Select the first (starting) date. This will automatically re-compute the maximum number of days shown
of the report (variable values will most likely differ from yours).
Edit the Days variable if you prefer to reduce the length of the report, otherwise the entire report will be
printed.
Select Page_Setup and configure the Width, Eol, and EolDly variables as shown. The Width variable
controls the number of sample columns printed and is settable from 1 to 30. Since the Hyperterminal
display is 80 characters wide, set this to 10 columns so that data does not wrap around to the next line.
Set Eol for CR/LF, and EolDly to 0.
Escape from Page_Setup and select Start_Printing. “Printing” will begin flashing, and you may stop at
any time by touching the Esc key.
►First=07/13/06
Days= 2 of 2
Page_Setup
Start Printing
>Menu >Setup >DataLog >Print
Sensor ►DataLog
Alarms Display
Auto-T System
4-20mA
>Menu >Setup
Setup
Review_Tabular
Review_Graphic
►Print
>Menu >Setup >DataLog
First=07/13/06
►Days= 1 of 2
Page_Setup
Start Printing
>Menu >Setup >DataLog >Print
►Width= 10 Sampls
Eol=CR/LF
EolDly=0 ms
>Menu >Setup >DataLog >Print
First=07/13/06
Days= 1 of 2
Page_Setup
►Start Printing
>Menu >Setup >DataLog >Print
First=07/13/06
Days= 1 of 2
Page_Setup
Printing
>Menu >Setup >DataLog >Print
