Atlas Copco Dynapac F3030C User Manual

D21 16
131
Red
P091
3
091
3
Accelerator pedal or lever position sensor
circuit-voltage above normal, or shorted to high
source
X
132
Red
P091
4
091
4
Accelerator pedal or lever position sensor
circuit-voltage below normal, or shorted to low
source
X
133
Red
P029
3
29
3
Remote accelerator pedal or lever position
sensor circuit-voltage above normal, or shorted
to high source
X
134
Red
P029
4
29
4
Remote accelerator pedal or lever position
sensor circuit-voltage below normal， or
shorted to low source
X
135
Amber
P100
3
100
3
Engine oil pressure sensor circuit-voltage
above normal, or shorted to high source
X
141
Amber
P100
4
100
4
Engine oil pressure circuit-voltage below
normal， or shorted to low source
X
143
White
P100
1
100
1
Engine oil pressure low-warning
X
144
Amber
P110
3
110
3
Engine coolant temperature sensor
circuit-voltage above normal, shorted to high
source
X
145
Amber
P110
4
110
4
Engine coolant temperature sensor
circuit-voltage below normal, or shorted to low
source
X
147
Red
P091
8
091
8
Accelerator pedal or lever position sensor
circuit-low frequency
X
148
Red
P091
8
091
8
Accelerator pedal or lever position sensor
circuit-high frequency
X
151
White
P110
0
110
0
Engine coolant temperature high-data valid but
above normal operational range-most severe
level
X
153
Amber
P105
3
105
3
Intake manifold #1temperature sensor circuit-
voltage above normal, or shorted to high source
X
154
Amber
P105
4
105
4
Intake manifold #1 temperature sensor circuit-
voltage below normal, or shorted to low source
X
155
White
P105
0
105
0
Intake manifold #1 temperature high-data valid
but above normal operational range-most
severe level
X
219
White
P17
1
1380
1
Centinel engine oil level compensation tank low
X
